Mixture-of-Experts (MoE) is a sparsely-activated architecture that scales large language model (LLM) capacity while keeping per-token compute low. Because its operations account for a large share of total compute time, inefficiencies there directly raise request latency and cost. Therefore, optimizing MoE operations through kernel engineering offers the largest opportunity for performance gains.

Fused MoE is a key optimization technique for the MoE architecture. A fused MoE system merges token routing, data shuffling, and specialized network calculations into a single batched operation on the GPU. This replaces executing those routing and expert computations as separate, sequential loop operations. While this provides latency advantages, it also brings complexity in kernel implementations and debugging capability. High GPU utilization for this architecture requires hardware-specific optimizations.

In this post, we describe the different kernel optimizations we implemented for fused MoE models and show you how you can benefit from this work. We used a representative MoE model as our primary example.

To maximize tensor processing throughput, the NVIDIA Hopper architecture relies on the Warp Group Matrix Multiply Accumulate (WGMMA) instruction protocol, which executes collectively across a cooperative warpgroup of 128 threads. This operand asymmetry is fundamentally an instruction set architecture (ISA)-level property. mma_async assembly definition, the hardware fixes the matrix row dimension (M) at a constant scale of 64 to define its parallel thread-mapping topology. The column dimension (N) remains highly variable. Operand A strictly maps across this fixed M dimension (using registers or shared memory), and Operand B maps across the variable N dimension (through a shared memory descriptor).
